RG-AT100S-3:
– Support 3.2m Length Of Rail / Single Door / <120KG Per Door
– 700 – 1300mm Width of Door Leaf
– 1350 – 2400mm Width of Door Opening
– AC 110-220V +/- 10%, 50-60hZ Power Supply
– 150 – 460mm/s Adjustable Opening Speed
– 130 – 460mm/s Adjustable Closing Speed
– 0 ~ 8s Adjustable Door Hold Open Time
– <40N Manual Force
– DC 24V, 65W (DC, Brushless) Motor
RG-AT100D-4:
– Support 4.2m Length Of Rail / Single Door / <120KG Per Door
– 700 – 1300mm Width of Door Leaf
– 1350 – 2400mm Width of Door Opening
– AC 110-220V +/- 10%, 50-60hZ Power Supply
– 150 – 460mm/s Adjustable Opening Speed
– 130 – 460mm/s Adjustable Closing Speed
– 0 ~ 8s Adjustable Door Hold Open Time
– <40N Manual Force
– DC 24V, 65W (DC, Brushless) Motor
RG-AT100D-5:
– Support 5m Length Of Rail / Single or Double Door / <100KG Per Door for Double Door Solution
– 600 – 1200mm Width of Door Leaf
– 2300 – 4800mm Width of Door Opening
– AC 110-220V +/- 10%, 50-60hZ Power Supply
– 150 – 460mm/s Adjustable Opening Speed
– 130 – 460mm/s Adjustable Closing Speed
– 0 ~ 8s Adjustable Door Hold Open Time
– <40N Manual Force
– DC 24V, 65W (DC, Brushless) Motor
RG-AT100D-6
-Support 6m Length Of Rail / Single or Double Door / <100KG Per Door for Double Door Solution
-600 – 1200mm Width of Door Leaf
-2300 – 4800mm Width of Door Opening
-AC 110-220V +/- 10%, 50-60hZ Power Supply
-150 – 460mm/s Adjustable Opening Speed
-130 – 460mm/s Adjustable Closing Speed
-0 ~ 8s Adjustable Door Hold Open Time
-<50N Manual Force
-DC 24V, 65W (DC, Brushless) Motor
